Five Brush Sweeper
Five brush
| Component Name | Serial Number | project | Parameter values/specifications |
| Complete vehicle | 1 | Model | YX-G22E |
| 2 | Sweeping width | 2200mm | |
| 3 | Main brush width | 800mm | |
| 4 | working efficiency | 10000-16000m²/h | |
| 5 | working hours | 3-8h | |
| 6 | Dustbin capacity | 200L | |
| 7 | Side-brush diameter | Front 600mm Middle 600mm | |
| 8 | Walking speed | 0-14km/h | |
| 9 | Overall dimensions | 2350*2200*2100mm | |
| 10 | water tank | 200L | |
| 11 | Vacuumfiltrationarea | 12m² | |
| 12 | Tyre type | Front 400-8, rear 400-8 solid tyre | |
| 13 | control mode | Intelligent control system (timed dustshaking function) | |
| Warning lights | 1 | Headlight | Four way LED headlights |
| 2 | tail light | Steering+braking+drivingintegratedtaillights | |
| 3 | Alarm lamp | Top operation warning light | |
| 4 | HD reverse camera | ||
| Storage battery | 1 | Type | Lead acid maintenance free (optionalwith lithium battery) |
| 2 | Battery capacity | Standard48V-150AH*6/200AH*8/240AH*8lead-acid battery | |
| Electrical machinery | 1 | Walking motor | 1200W intelligent gear change |
| 2 | Rolling brush motor | 1200W | |
| 3 | side-brush motor | 4*100W | |
| 4 | Motor voltage | 48V | |
| High pressure water pump | 1 | High pressure fog-cannon range | 6-10m |
| 2 | High pressure water-gun range | 10-18m | |
| 3 | power | 1500W | |
| 4 | Pressure range | 0-13Mpa | |
| 5 | Max rate of flow | 11L/min | |
| Rearview mirror | 1 | model | Dedicated for sweeping vehicles |
| Note: Standard double fan. Machine performance: The combination of suction, sweeping, and spraying effectivelysuppresses dust and thoroughly cleans ground waste and dust. Place of use: Used for cleaning workshop, parks, streets, lanes, docks, propertycommunities, warehouses, sports venues, schools, airports, and other areas in thefactory area. The cleaning efficiency is 10 times that of the traditional manual cleaning, and one sweeper can replace 8-12 Cleaner. | |||
sn YX-4L Sweeper Parameter ConTigurat
